ZL930 Wheel Loader

Factory Direct
Training on Arrival
One-year warranty
Rated Load: 1600Kg
Bucket Capacity: 0.6cbm
Rated Power: 51Kw
Product Detail
  • 1.The rising force is large, the high-position unloading material is automatically leveled, and the working device has a short action time, which improves the efficiency of the whole machine.

  • 2.Air cap oil assisted braking system, caliper disc brake.

  • 3.Split type hydraulic torque converter, not easy to high temperature, easy maintenance.

  • 4.The forward-leaning front frame has long unloading distance and large lifting weight.

  • 5.Electronic flameout, automatic power off, no switch.

  • 6.Pilot valve hydraulic operation, optional air conditioning.

Model

ZL930

Rated load (Ton)

1.6

Engine model

Huadong 4102

Rated power (Kw)

51

Max. discharging height (mm)

3200

Max.lifting height (mm)

3600

Bucket width (mm)

1800

Rated bucket capacity (m³)

0.6

Tyre model

20.5-16

Overall dimension (mm)

5400*1800*2750

Brake system

Oil brake
