Rich configuration
●Two big anticorrosive sprinkling cisterles connected design, large capacity, electric control pressure intermittent sprinkling water.
●Equipped with cab, optional air-conditioning or anti-roll frame
●The overall shape is beautiful with the streamline design, and the console have a good view.
Manipulation
●Hydraulic walking brake, electric control disc parking brake, equipped with emergency towing device, good safety performance
●The articulated steering makes it flexible.
Parameter name | HWD10 |
Operating weight (Kg) | 10000 |
Exciting force (KN) | 110/65 |
Vibration frequency (Hz) | 40/46 |
Nominal amplitude (mm) | 0.75/0.35 |
Gradeability (%) | 30 |
Engine model | Cummins 4BT3.9-C110 |
Rated power/rated speed (kW/rpm) | 82kw/2400rpm |
Overall dimensions of machine (mm) | 4420*1900*2950 |
Forward speed (km/h) | F1: 0-6, F2: 0-12 |
Reversing speed (km/h) | R1: 0-6, R2: 0-12 |
Wheelbase (mm) | 3300 |
Fuel tank (L) | 150 |
Compacting width (mm) | 1700 |
