Rich configuration
●Electrically controlled water-spray, highefficient and water- saving
●Emulsified liquid tank
●Wear-resistant scraper can be lift and fixed during transportation
Manipulation
●Forward/reverse and vibrating all controlled by the integrated control lever.
●The engine start is with neutral safty structure realised by the handle
●Integrated micro computer control panel
Hydraulic system
●It's applied with double drive traveling system composed of imported plunger pumps and plunger motors and is equipped with automatic parking brake mechanism.
●The vibrating drum is driven by imported hydraulic parts, with free changeover between single and double vibrating modes.
●The hydraulic articulated steering system features flexible motions and effectively adapts to diversified working conditions.
Engine
●Equipped with imported Yanmar engine, stronger power with less fuel consumption
Parameter name | HWD03 |
Operating weight (Kg) | 2900 |
Exciting force (KN) | 30 |
Vibration frequency (Hz) | 60 |
Nominal amplitude (mm) | 0.5 |
Gradeability (%) | 40 |
Engine model | Yanmar 388 |
Rated power/rated speed (kW/rpm) | 26.9kw/3000rpm |
Overall dimensions of machine (mm) | 2800*1450*2100 |
Forward speed (km/h) | 0-12 |
Reversing speed (km/h) | 0-12 |
Wheelbase (mm) | 1760 |
Fuel tank (L) | 40 |
Compacting width (mm) | 1200 |
