Engine
●Equipped with high quality Cummins engine, stronger power with less fuel consumption
Hydraulic system
●Sauer driving and vibrating system brings stability and reliability.
●Hydraulic dual - wheel drive, infinitely variable, hydraulic steering, easy to operate
●Double frequency and double amplitude vibration, makes sure the excellent effectiveness of compaction
Parameter name | HW14 |
Operating weight (Kg) | 14000 |
Exciting force (KN) | 310/200 |
Vibration frequency (Hz) | 30/35 |
Nominal amplitude (mm) | 1.65/0.70 |
Gradeability (%) | 45 |
Engine model | Weichai WP6G140E22 |
Rated power/rated speed (kW/rpm) | 105kw/2200rpm |
Overall dimensions of machine (mm) | 6140*2280*3100 |
Forward speed (km/h) | F1: 0-5.5, F2: 0-10 |
Reversing speed (km/h) | R1: 0-5.5, R2: 0-10 |
Wheelbase (mm) | 3100 |
Fuel tank (L) | 240 |
Compacting width (mm) | 2130 |
Hengwang Group aims to provide you with complete engineering equipment solutions to reduce your costs and increase your profits.
Fill in the form to get the latest product parameters and the lowest price.
