High operating comfort
● The machine adopts three-stage shock-absorbing and proprietary sealing mechanisms to achieve low vibration and low noise.
● The instrument panel, seat, and control box of the cab are arranged ergonomically to achieve high operating comfort.
● The full-hydraulic drive and one-speed stepless speed regulation guarantee simple operations.
Working performance
● The steel drum with "five-center-in-one" design is applied and the difference between left and right amplitudes of vibrating drum is controlled within 3% to effectively guarantee the road evenness.
● The 7-speed sprinkler guarantees more reasonable match between sprinkling volume and traveling speed.
Parameter name | HW13D |
Operating weight (Kg) | 13000 |
Exciting force (KN) | 150/86 |
Vibration frequency (Hz) | 48/50 |
Nominal amplitude (mm) | 0.66/0.36 |
Gradeability (%) | 30 |
Engine model | BF4M2012 |
Rated power/rated speed (kW/rpm) | 98/2300 |
Overall dimensions of machine (mm) | 5775*2370*3133 |
Forward speed (km/h) | F1:0-10 |
Reversing speed (km/h) | R1:0-10 |
Fuel tank (L) | 300 |
Compacting width (mm) | 2130 |
