● The installed Weichai WP12 electronically controlled engine conforms to the China-III non-road machinery emission regulation, featuring high intelligence and efficiency, high parts universality, and low maintenance cost.
● The installed electronically controlled hydrostatic drive system can automatically adapt the machine speed to the load variation and provide optimal operating speed under different working loads to achieve high productivity.
● Three operating modes are offered at the operator’s free choice depending on specific working condition and target need. The application of intelligent working condition match technology and reduce the composite fuel consumption by approximately 25% under light-load mode and increase the operating efficiency by 15%~20% under heavy-load mode.
● The imported Linde WISE controller is applied to control the traveling and operating of the machine and realize stable performances and high reliability.
● The multiple steering modes and the optional fan reverse function are provided to achieve higher intelligence, high efficiency, and higher safety of the machine.
● The malfunction self-diagnosis function is provided to accurately indicate the malfunction cause and orientation and shorten the downtime.
● The ergonomically integral sealed hexahedral cab with 8-point shock-absorbing mechanism features low noise and vibration, large space, and good vision.
● The suspended single accelerator pedal features small volume, large foot space, and high operation comfort.
● The extensively adjustable seat and armrests provide the driver with the most comfortable operation posture.
● The integrally sealed shock-absorbing system of the cab adopts sound-absorbing sponge and lowers the driver’s parotic noise to 85dB, featuring low vibration and noise.
● The standard A/C and heating system, the intelligent display and control terminal with integrated instruments, cigarette lighter, USB charging port, radio, toolbox, sun shade, and fire extinguisher to provide more abundant personalized driving/riding experience and guarantee the comfortable and safe driving/riding environment.
● The safety passage system of the machine guarantees the driver’s safety.
● The machine adopts double-circuit electronically controlled hydrostatic drive system to ensure good load self-adaptability, loaded and in-situ steering capability, stepless speed regulation, and high flexibility and efficiency and realize outstanding construction performance in narrow sites.
● The chassis system features long ground length, high ground clearance, stable driving, and excellent trafficability. Depending on the specific working condition, the semi-U blade, U-blade, coal blade, straight tilting blade, environmental sanitation blade, rock blade, ripper, traction frame, and rear protective frame can be installed to achieve high operating capability. The standard LED working lamps of higher illumination intensity improve the illumination capability during nighttime operations to achieve higher safety and reliability.
● The traveling is operated by single electronic control joystick and the working device is operated by single pilot joystick, featuring flexible, handy, and comfortable operations.
● The structural parts inherit the excellent quality of the mature products.
● The electric harnesses adopt seamless corrugated pipes and deconcentrators for branching, featuring high protection grade.
● The core electric and hydraulic parts adopt imported products, featuring stable and reliable quality and extremely high reliability.
● The modular structure design of the machine features easy disassembling and assembling, simple repairs, low failure rate, and easy maintenances.
● All lubricating and maintenance points of machine are directed to the outer side of machine body to achieve convenient and rapid maintenances.
|Parameter name||DH24-C2 XL (Extended version)||DH24-C2 CH (Coal version)||DH24-C2 RS (Rock version)||DH24-C2 LGP (Super-wetland version)||DH24-C2 WH (Environmental sanitation version)|
|Operating weight (Kg)||23820||24475||24429||26420||27030|
|Ground pressure (kPa)||68.3 (Standard)/62.7/58||64.5 (Standard)/59.6||70 (Standard)/64.3/59.5||40.9||41.8|
|Rated power/rated speed (kW/rpm)||157/1900 (Light-duty mode) ,179/1900 (Standard mode) , 198/1900 (Heavy-duty mode)||157/1900 (Light-duty mode) ,179/1900 (Standard mode) , 198/1900 (Heavy-duty mode)||157/1900 (Light-duty mode) ,179/1900 (Standard mode) , 198/1900 (Heavy-duty mode)||157/1900 (Light-duty mode) ,179/1900 (Standard mode) , 198/1900 (Heavy-duty mode)||157/1900 (Light-duty mode) ,179/1900 (Standard mode) , 198/1900 (Heavy-duty mode)|
|Overall dimensions of machine (mm)||6095*3640*3192||6474*3800*3192||6095*3640*3192||6255*4365*3228||6469*4365*3228|
|Forward speed (km/h)||0~11km/h (6.84mph)||0~11km/h (6.84mph)||0~11km/h (6.84mph)||0~11km/h (6.84mph)||0~11km/h (6.84mph)|
|Reversing speed (km/h)||0~11km/h (6.84mph)||0~11km/h (6.84mph)||0~11km/h (6.84mph)||0~11km/h (6.84mph)||0~11km/h (6.84mph)|
|Center distance of track (mm)||2000||2000||2000||2250||2250|
|Width of track shoes (mm)||560 (Standard)/610/660||610 (Standard)/660||560 (Standard)/610/660||910||910|
|Ground length (mm)||3050||3050||3050||3482||3482|
|Fuel tank (L)||390||390||390||390||390|
|Blade type||Semi-U blade||U-blade/coal blade||Rock blade||Straight tilting blade||Sanitation blade|
|Digging depth (mm)||540||545||540||550||550|
|Ripping depth (mm)||655||——||655||——||——|
